Migrate from CDK Pipelines to CDK Express Pipeline

AWS CDK Pipelines is a useful for deploying applications with AWS CodePipeline, but it is opinionated, can be complicated, and may not suit every use case. CDK Express Pipeline is another option that makes deployment simpler while keeping flexibility and good performance.

This guide shows how to move from CDK Pipelines to CDK Express Pipeline. It explains the reasons for switching, shares benchmark results, and highlights key differences. You can find the source code for both examples in this GitHub repository: https://github.com/rehanvdm/cdk-pipelines-migrate-to-express/

Why Migrate?

Challenges with CDK Pipelines

CDK Pipelines has some limits that can make it less suitable for teams who want fast, flexible, and easy-to-maintain CI/CD workflows:

• Tightly linked to CodePipeline: CDK Pipelines only works with AWS CodePipeline, which limits your CI/CD choices.
• Complicated asset management: It needs pre-asset generation steps and uses extra CodeBuild projects to build and push assets, increasing deployment time.
• Slower deployments: Self-mutation and the overhead of many CodeBuild steps slow down deployments, especially as you add more stacks, stages and waves.
• Fixed structure: Renaming stages or moving stacks can cause resources to be replaced because of how the CDK Stage construct works.
• Extra setup for cross-account or cross-region: CDK Pipelines needs extra stacks to manage deployments across accounts or regions.
• Authentication needs secrets: Connecting with GitHub or other CI/CD systems requires long-lived secrets stored in AWS Secrets Manager.

Benefits of CDK Express Pipeline

CDK Express Pipeline solves these problems with a simpler and faster approach:

• Works with any CI/CD system: It runs locally and with any CI/CD tool, not just AWS CodePipeline.
• Simple commands: Deployments use a single cdk deploy command. There is no need for separate asset pre-generation.
• Standard bootstrapping: It uses the same CDK bootstrap process you already know. There are no extra stacks for cross-account setups.
• Handles assets natively: Assets are managed like in standard CDK projects. There are no custom CodeBuild steps.
• Faster deployments: Deployments can be up to 5 times faster for first & pipeline changing deployments and 2+ times faster on normal deploys. It will become even faster over time, as CDK Pipelines tends to grow more bloated and slower with each additional stack, stage and wave.
• More flexible: You can rename stages or move stacks without causing unwanted resource replacements.
• Modern authentication: It supports OIDC integration with modern CI/CD systems, so you do not need long-lived secrets in Secrets Manager.

CDK Pipelines Setup

We use the CDK Pipelines Getting Started Guide as a reference for the CDK Pipelines setup. Then we show how to move this to CDK Express Pipeline. The goal is to deploy the MyLambdaStack in two regions, eu-west-1 and us-east-1.

We only highlight some code snippets and important steps. For the full code, see the repo at https://github.com/rehanvdm/cdk-pipelines-migrate-to-express/tree/main/cdk-pipelines

Important steps for CDK Pipelines setup:

• CDK Bootstrap all regions and set the --trust flag to the pipeline account you will deploy from.
• Create a new GitHub Personal Access Token (PAT) and store it in AWS Secrets Manager with the name github-token.
• A manual/local deployment (cdk deploy) is required the first time. This creates the pipeline and the initial CdkPipelinesStack stack. The pipeline will then deploy the rest of the resources.

Directory and File Structure

The directory structure:

We are currently following the guide’s structure, but I recommend a different project layout in my blog post: AWS CDK starter project - Configuration, multiple environments and GitHub CI/CD

The bin file is the entry point for the CDK application. It creates an instance of the CdkPipelinesStack class.

// bin/cdk-pipelines.ts

const app = new cdk.App();
new CdkPipelinesStack(app, 'CdkPipelinesStack', {
   env: { account: '581184285249', region: 'eu-west-1' },
});

The CdkPipelinesStack class defines the CDK Pipelines setup. We add a wave to the pipeline that deploys the MyPipelineAppStage in two regions, eu-west-1 and us-east-1.

The CodePipeline synth step installs, builds, and synthesizes the CDK application into CloudFormation templates. CodePipeline uses CodeBuild for all steps. This includes building assets, pushing assets to the right accounts and regions, and deploying the CloudFormation stacks from the templates.

// lib/cdk-pipelines-stack.ts

import { CodePipeline, CodePipelineSource, ShellStep } from 'aws-cdk-lib/pipelines';

export class CdkPipelinesStack extends cdk.Stack {
  constructor(scope: Construct, id: string, props?: cdk.StackProps) {
    super(scope, id, props);

    const pipeline = new CodePipeline(this, 'Pipeline', {
      pipelineName: 'MyPipeline',
      synth: new ShellStep('Synth', {
        input: CodePipelineSource.gitHub('rehanvdm/cdk-pipelines-migrate-to-express', 'main'),
        commands: [
          'npm ci',
          'npm run build',
          'npx cdk synth'
        ],
      })
    });

    const wave = pipeline.addWave('wave');
    wave.addStage(new MyPipelineAppStage(this, 'MyAppEU', {
      env: { account: '581184285249', region: 'eu-west-1' }
    }));
    wave.addStage(new MyPipelineAppStage(this, 'MyAppUS', {
      env: { account: '581184285249', region: 'us-east-1' }
    }));

  }
}

The MyPipelineAppStage class contains only the MyLambdaStack, which is the application stack we want to deploy.

// lib/my-pipeline-app-stage.ts

export class MyPipelineAppStage extends cdk.Stage {

   constructor(scope: Construct, id: string, props?: cdk.StageProps) {
      super(scope, id, props);

      const lambdaStack = new MyLambdaStack(this, 'LambdaStack');
   }
}

The MyLambdaStack class defines the Lambda function.

// lib/my-pipeline-lambda-stack.ts

export class MyLambdaStack extends cdk.Stack {
   constructor(scope: Construct, id: string, props?: cdk.StackProps) {
      super(scope, id, props);

      new Function(this, 'LambdaFunction', {
         runtime: Runtime.NODEJS_18_X,
         handler: 'index.handler',
         code: new InlineCode('exports.handler = _ => "Hello, CDK";')
      });
   }
}

We use eu-west-1 as the pipeline region. Deploying this CDK Pipelines application creates these CloudFormation stacks:

• eu-west-1
  • CdkPipelinesStack: Contains the CodePipeline, CodeBuild, and other resources for the pipeline.
  • MyAppEU-LambdaStack: Contains the Lambda function in the eu-west-1 region.
• us-east-1
  • CdkPipelinesStack-support-us-east-1: Created by CDK Pipelines to support cross-region deployments.
  • MyAppUS-LambdaStack: Contains the Lambda function in the us-east-1 region.

CDK Pipelines creates a support stack in us-east-1 for cross-region deployments. This stack creates an S3 bucket to store assets for this region. This is some of the extra work CDK Pipelines does instead of using the standard CDK bootstrapping process (the --trust flag) to share assets across regions.

Migrating to CDK Express Pipeline

CDK Express Pipeline makes deployment easier by letting you define your pipeline in a more direct way. We will deploy the same application in both regions, but with a simpler setup.

We use the CDK Express Pipeline tutorial but change the waves, stages, and stack names slightly to match the CDK Pipelines tutorial. This helps us compare the two setups. Naming changes made:

Entity	CDK Pipelines (before)	CDK Express Pipeline (after)
Wave	wave	Default
Stack	LambdaStack	AppStack

Important steps for CDK Express Pipeline setup:

• CDK Bootstrap all regions and set the --trust flag to the account you use for CDK deploy.
• Set up GitHub OIDC authentication between your GitHub repository and AWS. This lets GitHub Workflows authenticate with AWS without a long-lived secret. See the CDK Express Pipeline tutorial for details.

Directory and File Structure

The directory structure:

The bin file is still the entry point for the CDK application. We can set up the pipeline directly here without a separate stack. This means we only need 2 files, while the previous setup needed 4 files.

We use the functional way to define the pipeline. You can also use OOP and extend the ExpressWave and ExpressStage classes as described here

// bin/cdk-express-pipeline.ts

const app = new App();
const expressPipeline = new CdkExpressPipeline();

// === Wave 1 ===
const wave1 = expressPipeline.addWave('Default'); // Named "wave" in cdk-pipelines, "Default" fits better

// --- Wave 1, Stage US ---
const wave1StageUs = wave1.addStage('MyAppUS');
new MyLambdaStack(app, 'AppStack', wave1StageUs, {env: { account: "581184285249", region: "us-east-1" }});

// --- Wave 1, Stage EU ---
const wave1StageEu = wave1.addStage('MyAppEU');
new MyLambdaStack(app, 'AppStack', wave1StageEu, {env: { account: "581184285249", region: "eu-west-1" }});

expressPipeline.synth([
  wave1,
]);

We use GitHub Actions as our CI/CD system, so we create a Workflow file for the pipeline. The pipeline definition gives the same result as what the CDK Pipelines output produces, but with a simpler and flexible configuration.

// .github/workflows/deploy.yml

name: Deploy
on:
  push:
    branches:
      - main
env:
  FORCE_COLOR: 1
jobs:
  deploy:
    name: CDK Diff and Deploy
    runs-on: ubuntu-latest
    permissions:
      actions: write
      contents: read
      id-token: write
    steps:
      - name: Checkout repo
        uses: actions/checkout@v4

      - name: Set up node
        uses: actions/setup-node@v3
        with:
          node-version: 20
          cache: npm
      - name: Install dependencies
        run: npm install ci
      - name: Configure AWS credentials
        uses: aws-actions/configure-aws-credentials@v4
        with:
          role-to-assume: arn:aws:iam::581184285249:role/githuboidc-git-hub-deploy-role
          aws-region: eu-west-1
      - name: CDK deploy
        run: npm run cdk -- deploy '**' --require-approval never --concurrency 10

The MyLambdaStack class is the same as before, except it now extends ExpressStack instead of cdk.Stack.

// lib/my-pipeline-lambda-stack.ts

export class MyLambdaStack extends ExpressStack {
  constructor(scope: Construct, id: string, stage: ExpressStage, props?: cdk.StackProps) {
    super(scope, id, stage, props);

    new Function(this, 'LambdaFunction', {
      runtime: Runtime.NODEJS_18_X,
      handler: 'index.handler',
      code: new InlineCode('exports.handler = _ => "Hello, CDK";')
    });
  }
}

We again use eu-west-1 as the pipeline region. Deploying this CDK Express Pipeline application creates these CloudFormation stacks:

• eu-west-1
  • AppStack: Contains the Lambda function in the eu-west-1 region.
• us-east-1
  • AppStack: Contains the Lambda function in the us-east-1 region.

CDK Express Pipeline does not create any CodePipeline or support stacks in other regions. This reduces the number of stacks to 2 instead of 4. It also does not need a manual deployment to create the pipeline.

Comparing deployment times

CDK Express Pipeline is 5 times faster than CDK Pipelines on the first deployment and on deployments that change the pipeline. It is also 2 times faster than CDK Pipelines on later deployments that only change the application code. It will get even faster because CDK Pipelines will slow down as you add more stacks, stages and waves.

Let’s take a closer look at the deployment times of CDK Pipelines versus CDK Express Pipeline, comparing both local and CI deployments.

Local Deployment

The results of the local deployment times are:

	CDK Pipelines	CDK Express Pipeline
First Deployment (Local)	5 minutes 52 seconds	0 minutes 53 seconds
Deployment (Local) - Lambda code changes	not possible	0 minutes 49 seconds

CDK Pipelines

CDK Pipelines needs a manual deployment (cdk deploy 'CdkPipelinesStack') to create the first CdkPipelinesStack stack and any cross-region stacks. Once CodePipeline is created, it will start the application deployment with CodePipeline as if you pushed a commit to GitHub. It took 2 minutes and 12 seconds to deploy the CDK Pipelines stacks, then another 3 minutes and 40 seconds for the pipeline to deploy the application stacks. The total time for the first CDK Pipelines deployment is 5 minutes and 52 seconds.

It is not possible to use CDK deploy to update a CDK Pipelines application in the correct order. It will not respect waves and will deploy all stacks in parallel if possible. For this reason, it is marked as “not possible” in the table. You must use the pipeline itself to respect the wave order.

To be fair, you could deploy with the CDK CLI, but you would need to deploy the stacks by stack selector in the right order, even though you already defined this in the pipeline. This shows that CDK Pipelines applications are not meant for local deployment, but should only be deployed through the pipeline.

CDK Express Pipeline

CDK Express Pipeline is made to be deployed locally or in a CI/CD system. The first deployment with cdk deploy '**' took 53 seconds. It does not need to create any pipeline stacks and will respect the order of stacks in waves, so it is safe to use locally and in CI.

For the second local deployment, we changed the Lambda code and redeployed. It took 49 seconds to deploy.

CI Deployment

The results of the CI deployment times are:

	CDK Pipelines	CDK Express Pipeline
Deployment (CI) - Lambda code changes	2 minutes 33 seconds	1 minute 1 second
Deployment (CI) - Pipeline + Lambda code changes	4 minutes 45 seconds	1 minute 6 seconds

CDK Pipelines

It took 2 minutes and 33 seconds to deploy the CDK Pipelines application with CodePipeline when there were Lambda code changes.

For the Pipeline and Lambda code changes, we added an extra 'echo "Small change"', to the synth shell step of CodePipeline. Because CodePipeline is self mutating, it first deploys the CodePipeline stacks, then cancels that CodePipeline execution. This took 2 minutes and 37 seconds. It then creates a new CodePipeline execution to start with the correctly updated pipeline and deploy the Lambda code changes. This took 2 minutes and 8 seconds, so the total time for the Pipeline and Lambda code changes is 4 minutes and 45 seconds.

CDK Express Pipeline

CDK Express Pipeline took 1 minute and 1 second to deploy the application when there were only Lambda code changes.

It took 1 minute and 6 seconds to deploy the Pipeline and Lambda code changes. Pipeline changes do not affect the deployment time, as it does not need to self mutate.

Comparing Stack IDs

CDK Pipelines

CDK Pipelines creates stacks with these IDs:

• CdkPipelinesStack
• cross-region-stack-581184285249:us-east-1
• CdkPipelinesStack/MyAppUS/LambdaStack
• CdkPipelinesStack/MyAppEU/LambdaStack

To deploy only the application stacks locally, you would use the stack selector CdkPipelinesStack/**.

CDK Pipelines does not include the wave name in the stack ID. If you add a second wave called wave2, there is no way to select and deploy the stacks of wave and then, if successful, deploy the stacks of wave2.

CDK Express Pipeline

CDK Express Pipeline creates stacks with these IDs:

• Default_MyAppEU_AppStack
• Default_MyAppUS_AppStack

The stack IDs include the wave name. If you add a second wave called Default2, you can deploy the stacks of the first wave with cdk deploy 'Default/**' and then deploy the stacks of Default2 wave with cdk deploy 'Default2/**'. This makes it easy to deploy only the stacks of a specific wave.

Conclusion

CDK Express Pipeline is a simpler and more flexible option than CDK Pipelines. You can define your pipeline in a direct way, without complex pre-asset generation steps or extra support stacks. It is made for local or CI/CD deployment, so it is easier to use and faster to deploy.

CDK Express Pipeline is 5 times faster than CDK Pipelines on the first deployment and on deployments that change the pipeline. It is also 2 times faster on later deployments that only change the application code. CDK Express Pipeline will stay fast even as you add more waves, stages and stacks.

CDK Express Pipeline is a good choice for those who want a simple and flexible deployment process while keeping the power of AWS CDK.

---

---
